Hikmicro B21L Handheld Thermal Camera

Hikmicro B21L Handheld Thermal Camera

• IR resolution: 256 x 192px
• High-temperature alarm with speaker and torch alerts
• Wi-Fi connectivity

Featuring a 256 x 192px IR resolution, 40mK thermal sensitivity, and a temperature range of -20°C to +550°C, the Hikmicro B21L Handheld Thermal Camera is suitable for building, HVAC, and automotive applications. Image enhancement algorithms, coupled with a VOx detector ensure the Hikmicro B21L Handheld Thermal Camera captures clear, fully radiometric images. The Hikmicro B21L automatically tracks maximum, minimum, and centre temperatures. This allows you to spot temperature anomalies immediately. The camera offers an accuracy of ±2°C/2%. Furthermore, SuperIR functionality upscales the thermal image's resolution to 320 x 240px, while selectable thermal colour palettes allow you to adjust the camera to suit your application. A 25Hz frame rate ensures footage is smooth, even when panning across scenes or tracking moving targets. Images are displayed on the 3.2-inch LCD.

High-Temperature Alarm

When high temperatures are detected, the built-in speaker and torch will issue alerts.

Macro Mode

When used with a clip-on macro lens, the B21L can take temperature readings of components as small as 500 microns. This makes the camera perfect for pinpointing faults on printed circuit boards.

Wi-Fi Connectivity

Integrated Wi-Fi also allows you to stream thermal images to a smartphone or tablet with Hikmicro’s Viewer App installed, enabling easy collaboration.

Hikmicro Analyser Software

Included is Hikmicro’s Analyser Software. It features tools such as points, lines, rectangles, circles and polygons that can be used to analyse thermal data. The Hikmicro Analyser Software also has the capability to create reports.

Designed for fast fault finding, the Hikmicro B21L Handheld Thermal Camera is an accurate, adaptable infrared imager.

Key Features

• Thermal camera suitable for building, HVAC, and automotive applications
• IR resolution: 256 x 192px
• Thermal sensitivity: 40mk
• Temperature range: -20°C to +550°C
• Image enhancement algorithms
• VOx detector
• Clear, fully radiometric images
• Automatically tracks maximum, minimum, and centre temperatures
• Accuracy: ±2°C/2%
• SuperIR functions: increases resolution to 320 x 240px
• Selectable thermal palettes
• Frame rate: 25Hz
• High-temperature alarm with speaker and torch alerts
• Clip-on macro lens
• Take temperature readings of components as small as 500 microns
• 3.2-inch LCD
• Wi-Fi connectivity
• Stream thermal images to a smartphone or tablet with the Hikmicro Viewer App installed
• Supplied with Hikmicro Analyser Software
• Designed for fast fault finding
• An accurate, adaptable thermal imager

What’s Included?

• Hikmicro B21L Handheld Thermal Camera
• Wrist Strap
• Charger
• USB Cable
• Power Adapter
• Quick Start Guide
• Calibration Certificate
